Precision Clean Regulator SRP

Series/CAD	Port size	Set pressure (MPa)
SRP	M5,1/8	Low pressure type: 0.005 to 0.2 High pressure type: 0.01 to 0.4
Features	High precision low flow consumption stainless steel regulator Bleed air flow 0.5 L/min (ANR) or less (0.2 MPa at outlet pressure) Setting sensitivity: 0.3% F.S. Repeatability: 1% F.S.

Clean Regulator/Fluororesin Type SRF

Series/CAD		Applicable tubing O.D.		Set pressure (MPa)
		Metric size	Inch size
SRF	Integrated with fitting	φ4 to φ19φ	1/8 to φ3/4	0.02 to 0.4
	With nut	Fitting size: 2 to 6
	Tube extension	--	Tubing O.D. φ1/4 to φ3/4
Features	Wetted parts Body: New PFA Diaphragm: PTFE Recommended maximum flow rate: 20 L/min (SRF50) (0.3 MPa at inlet pressure, fluidization)

Regulator for 2 MPa ARX

Series/CAD	Port size	Set pressure (MPa)	Filtration (μm)
ARX20	1/4,1/8	0.05 to 0.85
Features	Compatible with inlet supply pressure of 2.0 MPa. Ideal for discharge pressure adjustment on a small compressor. Piston type Ideal for the pressure adjustment of air blowing applications

Direct Operated Regulator for 6.0 MPa (Relieving Type) VCHR

Series/CAD	Type	Port size	Set pressure (MPa)
VCHR30/40	Direct operated regulator (Relieving type)	G3/4,1,1^1/2	0.5 to 5.0 (Inlet pressure 6.0)
Features	Service life: 10 million times Improved durability in high pressure environments using a polyurethane elastomer poppet. Uses NSF-H1 approved grease at guide rings (sliding parts). Improved durability using a metal seal type relief valve. Uses special fluororesin seal for sliding parts. Stable unattached response, and not easily affected by pressure.
